Nqe lus piav qhia:
30W mopa laser marking tshuab piv nrog Cov Cim Cim technologies siv ncaj qha los yog consumables rau kos nto. Nws txwv qhov tseeb, durability, thiab cov ntaub ntawv suav nrog. Nyob rau hauv sib piv, lub fiber laser npav tshuab siv optical fibers xa high-density lub teeb los ua hauj lwm ntawm cov khoom. Raws li, nws muab cov txiaj ntsig zoo tshaj plaws, cov cim tsis tuaj yeem, thiab ua haujlwm siab thoob plaws ntau yam ntaub ntawv yam tsis muaj kev sib cuag lub cev lossis khoom siv. Laser npav tshuab kuj tseem muaj cov txheej txheem ceev ceev thiab kev saib xyuas me me, uas feem ntau hais txog cov ntsiab lus rau cov tuam txhab
specification:
|
Qauv |
D2000c-plus |
D3000c-plus |
D6000c-plus |
D12000c-plus |
|
Laser zog |
20W |
30W |
60W |
120W |
|
Cov khoom siv tshuab |
Anodized aluminium (Laser taub hau) & Stainless hlau (Control Unit) |
|||
|
Laser hom |
Fiber Laser Source |
|||
|
Laser wavelength |
1064nm ua |
|||
|
Scan txoj kev |
High-precision 2-dimensional scanning method |
|||
|
Marking ceev |
Tsawg dua lossis sib npaug li 18000mm / s |
|||
|
Main tswj |
SUNINE V5 muaj kev sib koom ua ke motherboard nrog 10-inch controller |
|||
|
Kev khiav haujlwm |
Linux |
|||
|
Txias qhov system |
Cua txias |
|||
|
Hom kev cim |
Ob lub dot matrix thiab vector |
|||
|
Reflector loj |
Txheem: 8.5mm |
|||
|
Kos teb |
Txheem: 110mm × 110mm |
|||
|
Txoj kev tso chaw |
Red-light positioning |
|||
|
Kab ntawm cov cim |
Tsis muaj kev txwv nyob rau hauv lub cim teb |
|||
|
Cov kab ntau lawm ceev |
0 ~ 300m / min (nws txawv raws li cov ntaub ntawv thiab cov ntawv luam tawm) |
|||
|
Lus |
Suav Simplified, Suav tsoos, Lus Askiv, German, Mev, Fabkis, Italian, Nyiv, Kauslim, Portuguese, Hindi, Lavxias, Turkish, Arabic, Persian, thiab lwm yam. |
|||
|
Cov ntaub ntawv hom |
BMP/DXF/PNG/JPEG/PLT/JPG |
|||
|
Hom code |
Code128A, Code128B, Code128C, Code39, Code93, EAN-13,PDF417, 01 Code; QR, DM, GS1-DM, AztecCode, HanxinCode, DotCode |
|||
|
Fais fab mov |
220V / 50-60Hz (110V yeem) |
|||
|
Max. noj |
Tsawg dua lossis sib npaug li 500W |
|||
|
N.W. |
31kg ua |
35kg ua |
||
|
Laser taub hau loj |
458mm x 84mm x 111mm |
527mm x 102mm x 120mm |
||
|
Tswj chav tsev loj |
492mm x 383mm x 160mm |
522mm x 460mm x 160mm |
||
|
Interfaces |
RS {{0}}C/USB2.0/Ethernet, I/O |
|||
|
Cov xwm txheej ua haujlwm |
0-45 degree ; 30% -85% RH (Tsis muaj condensing) |
|||
Qhov zoo:
Qhov zoo ntawm 30W mopa laser npav tshuab
1. Txwv precision thiab raug
Cov txheej txheem kev kos npe ib txwm tsis muaj qhov tseeb ntawm micron. Yog li ntawd, rau kev lag luam uas xav tau ntau dua xws li cov khoom siv hluav taws xob thiab cov khoom siv kho mob, cov txheej txheem coding ib txwm tsis tuaj yeem muab cov kev daws teeb meem txaus siab.
2. Kev cuam tshuam ntawm kev coding ib txwm muaj thiab kev kos cim rau ib puag ncig
Cov txheej txheem kos npe ib txwm muaj xws li inkjet siv ntau tus cwj mem thiab tsis yog ib puag ncig tus phooj ywg. Tsawg siv tus cwj mem lossis ribbon uas yog cov khoom siv uas peb pom hauv inkjet thiab TTO, pab txo cov dej thiab av paug.
3. Cov txheej txheem siv sijhawm thiab nce sijhawm poob
Cov cim cim cim yuav tsum tau teeb tsa ntev thiab hloov kho rau cov khoom sib txawv thiab cov qauv, uas tuaj yeem cuam tshuam kev tsim khoom. Yog li ntawd, uptime thiab manufacturing efficiency yog txo. Kev saib xyuas tsis tu ncua cuam tshuam rau kev ua haujlwm thiab kev tsim tawm hauv txoj hauv kev zoo.
Daim ntawv thov:
Raws li lub tuam txhab muaj npe nrov ntawm cov tshuab laser npav, SUNINE LASER muaj cov tshuab fiber ntau tshwj xeeb, nrog nws cov D series 30W mopa fiber ntau laser npav tshuab ua tus neeg ua yeeb yam zoo tshaj plaws hauv kev muab cov cim meej thiab zoo sib xws ntawm cov hlau thiab xaiv cov khoom tsis yog hlau xws li ABS. thiab PVE PVC.
Cim npe nrov: 30w mopa laser npav tshuab, Tuam Tshoj 30w mopa laser npav tshuab manufacturers, lwm tus neeg, Hoobkas
